Huawei AirEngine 5761R-11 und AirEngine 5761R-11E
They are Huawei's Wi-Fi 6 (802.11ax) outdoor access points (APs). AirEngine 5761R11 provides services on 2.4 GHz (2x2 MIMO) and 5 GHz (2x2 MIMO) frequency bands, achieving a device rate of up to 1.775Gbit/s ,AirEngine 5761R-11E provides services on 2.4 GHz (2x2 MIMO) and 5 GHz (2x2 MIMO) frequency bands or 5 GHz (2x2 MIMO) +5 GHz (2x2 MIMO) frequency bands, achieving a maximum rate of 2.4 Gbit/s. These outdoor APs stand out with excellent outdoor coverage performance, IP68 waterproof and dustproof design, and strong urge protection capability. AirEngine 5761R-11 and AirEngine 5761R-11E provide uplink optical and electrical ports, allowing customers to select different deployment modes and saving customers' investment. These strengths make Huawei's Wi-Fi 6 outdoor APs ideal for highdensity scenarios such as stadiums, squares, pedestrian streets, and amusement parks.
| Technical Data | ||
| Technical specifications | Dimensions (H x W x D) | 69 x 200x 200 mm |
| Weight | AirEngine 5761R-11: 1.91 kg AirEngine 5761R-11E: 2.04 kg | |
| Interface type | 1 x10/100M/1GE 1 x SFP NOTE: GE electrical port can support PoE input | |
| Bluetooth | Build in BLE5.2 | |
| LED indicator | Indicates the power-on, startup, running, alarm, and fault states of the system | |
| Power specifications | Power input | PoE power supply: In compliance with 802.3at/af. NOTE: When 802.3af power is supplied, the AP will operate with restrictions, the details refer to the Specification Query Tool |
| Maximum power consumption | AirEngine 5761R-11: 17.7W AirEngine 5761R-11E: 19.6W NOTE: The actual maximum power consumption depends on local laws and regulations. | |
| Environmental specifications | Operating temperature | -40°C to +65°C |
| Storage temperature | -40°C to +85°C | |
| Operating humidity | 0% to 100% | |
| Dustproof and waterproof grade | IP68 | |
| Altitude | -60 m to +5000 m | |
| Atmospheric pressure | 53 kPa to 106 kPa | |
| Radio specifications | Antenna type | AirEngine 5761R-11: Built-in antennas AirEngine 5761R-11E: External antennas NOTE: 2.4GHz Horizontal beamwidth: 65°，2.4GHz Vertical beamwidth: 40°.5GHz Horizontal beamwidth: 65°，5GHz Vertical beamwidth: 20° |
| Antenna gain | 2.4GHz: 10dBi 5GHz: 11dBi | |
| Maximum number of SSIDs for each radio | ≤ 16 | |
| Maximum number of users | ≤ 1024 (512/Radio) NOTE: The actual number of users varies according to the environment | |
| Maximum transmit power | 2.4G: 28dBm (combined power) 5G: 27dBm (combined power) NOTE: The actual transmit power depends on local laws and regulations. | |
| Power increment | 1 dBm |
