USG6530F-D
To see the prices, please log in or register here.
Article Nr 02355FBU
HUAWEI HiSecEngine USG6500F Series AI Firewalls
| Basic Information | |
| Part Number | 02355FBU |
| Model | USG6530F-D-AC |
| Description | USG6530F-D(HTM)-AC Host(10*GE RJ45+2*10GE SFP+,1*Adapter) |
| Technical Specifications | |
| Installation Type | Rack,Work bench,Against the wall |
| Cabinet installation standard | Cabinet with a depth of 300 mm or above |
| Chassis height [U] | 1 |
| Wide [mm] | 250 mm |
| Depth [mm] | 210 mm |
| Height [mm] | 43.6 mm |
| Weight without packaging [kg(lb)] | 1.55 (3.42) |
| Weight with packaging [kg(lb)] | 2.72 (6.0) |
| Typical power consumption [W] | 20.9 |
| Maximum power consumption [W] | 24.1 |
| Typical heat dissipation [BTU/hour] | 71.3 |
| Maximum heat dissipation [BTU/hour] | 82.2 |
| Heat dissipation mode | Has no fan and uses natural cooling. |
| Power supply mode | Power adapter external |
| Rated input voltage [V] | 100 V to 240 V, 50 Hz/60 Hz |
| Input voltage range [V] | 90 V to 264 V, 47 Hz to 63 Hz |
| Maximum output power [W] | 36 W/power module |
| Maximum input current [A] | 1 A/power module |
| CPU | 1 CPU, 4 cores/CPU, up to 1.2 GHz |
| Memory | 4 GB DDR4 ECC memory |
| NOR Flash | 64 MB |
| NAND Flash | 2 GB |
| Hard disk | Optional. Purchase one 64-GB micro SD card from Huawei as required. |
| Number of power modules | 1 |
| Number of fan modules | 0 |
| Types of fans | None |
| Long-term operating temperature [°C(°F)] | 0°C to 45°C (32°F to 113°F) |
| Storage temperature [°C(°F)] | –40°C to +70°C (–40°F to +158°F) |
| Long-term operating relative humidity [RH] | 5% RH to 95% RH, non-condensing |
| Storage relative humidity [RH] | 5% RH to 95% RH, non-condensing |
| Long-term operating altitude [m(ft.)] | 0 m to 5000 m |
| Storage altitude [m(ft.)] | 0 m to 5000 m |
| MTBF [year] | 62.96 |
| MTTR [hour] | 1 |
| Availability | 0.999998 |
| Console port | RJ45 |
| Eth Management port | RJ45 |
