S5735-L24T4XE-A-V2
To see the prices, please log in or register here.
Article Nr 98012011
Huawei CloudEngine S5735-L-V2 series switches
They are ideal for scenarios such as enterprise campus network access and gigabit to the desktop. Built on next-generation, high-performance hardware and software platform, CloudEngine S5735-L-V2 switches stand out with compelling features such as intelligent stack (iStack), flexible Ethernet networking, and diversified security control. They support multiple Layer 3 routing protocols and provide high performance and service processing capabilities.
| Basic Information | |
| Part Number | 98012011 |
| Model | S5735-L24T4XE-A-V2 |
| Description | S5735-L24T4XE-A-V2 (24*10/100/1000BASE-T ports, 4*10GE SFP+ ports, 2*12GE stack ports, AC power) |
| Technical Specifications | |
| Chassis material | Metal |
| Height [mm] | 43.6 mm |
| Depth [mm] | 220.0 mm |
| Wide [mm] | 442.0 mm |
| Chassis height [U] | 1 |
| Weight with packaging [kg(lb)] | 3.46 (7.63) |
| Weight without packaging [kg(lb)] | 2.34 (5.16) |
| Maximum power consumption [W] | 37.03 |
| Typical power consumption [W] | 28.48 |
| Heat dissipation mode | Air cooling for heat dissipation, intelligent fan speed adjustment |
| Maximum heat dissipation [BTU/hour] | 126.36 |
| Typical heat dissipation [BTU/hour] | 97.18 |
| Power supply mode | AC built-in |
| Input voltage range [V] | AC input: 90 V AC to 264 V AC; 45 Hz to 65 Hz |
| Rated input voltage [V] | AC input: 100–240 V AC; 50/60 Hz |
| Maximum input current [A] | 0.8 A |
| Number of power slots | 0 |
| Number of card slots | 0 |
| Memory | 2 GB |
| Flash memory | Physical space: 1 GB |
| Redundant power supply | Not supported |
| Types of fans | Built-in |
| Noise at normal temperature (acoustic power) [dB(A)] | 47 |
| Noise at normal temperature (acoustic pressure) [dB(A)] | 35 |
| Airflow direction | Air intake from left and front, air exhaustion from right |
| Storage temperature [°C(°F)] | –40°C to +70°C (–40°F to +158°F) |
| Long-term operating temperature [°C(°F)] | -5°C to +50°C (23°F to 122°F) at an altitude of 0-1800 m (0-5905.44 ft.) |
| Restriction on the operating temperature variation rate [°C(°F)] | When the altitude is 1800–5000 m (5906–16404 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). Devices cannot start when the temperature is lower than 0°C (32°F). |
| Long-term operating relative humidity [RH] | 5% RH to 95% RH (non-condensing) |
| Storage altitude [m(ft.)] | 0-5000 m (0-16404 ft.) |
| Long-term operating altitude [m(ft.)] | 0–5000 m (0–16404 ft.) |
| MTBF [year] | 68.70 |
| MTTR [hour] | 2 |
| Availability | > 0.99999 |
| Maximum number of physical ports on the entire device | 30 |
| Maximum number of 100GE ports | 0 |
| Maximum number of 40GE ports | 0 |
| Maximum number of 25GE ports | 0 |
| Maximum number of 10GE ports | 4 |
| Maximum number of GE ports | 28 |
| Maximum number of FE ports | 24 |
| 10GE optical interface | 4 |
| 1000M electrical interface | 24 |
| USB | Supported |
| Console port | RJ45 |
| Eth Management port | Not supported |
| Service port surge protection [kV] | Common mode: ±7 kV |
| Power supply surge protection | Differential mode: ±6 kV; common mode: ±6 kV |
| RPS input | Not supported |
| PoE | Not supported |
