PAC600S56-CB
To see the prices, please log in or register here.
Article Nr 02313PAC
600W AC&240V DC Power Module (Back to Front,Power panel side exhaust)
| Basic Information | |
| Part Number | 02313PAC |
| Model | PAC600S56-CB |
| Description | 600 W PoE AC&240 V DC Power Module (Back to Front, Power panel side exhaust) |
| Technical Specifications | |
| Dimensions without packaging (H x W x D) [mm(in.)] | 40 mm x 90 mm x 215 mm (1.6 in. x 3.5 in. x 8.5 in.) |
| Weight without packaging [kg(lb)] | 1.1 kg (2.43 lb) |
| Number of inputs | 1 |
| Number of outputs | 1 |
| Rated output voltage [V] | 56 V |
| Rated input voltage [V] | 100 V AC to 130 V AC; 50/60 Hz 200 V AC to 240 V AC; 50/60 Hz 240 V DC |
| Input voltage range [V] | 90 V AC to 290 V AC; 45 Hz~66 Hz 190 V DC to 290 V DC |
| Maximum input current [A] | 100 V AC to 130 V AC: 8 A 200 V AC to 240 V AC: 8 A 240 V DC: 4 A |
| Rated output current [A] | 100 V AC to 130 V AC input: 5.36 A 200–240 V AC and 240 V DC input: 10.72 A |
| Rated output power [W] | 100 V AC to 130 V AC input: · Total power: 300 W 200 V AC to 240 V AC input and 240 V DC input: · Total power: 600 W |
| Hot swapping | Supported |
| Power dissipation Mode | Heat dissipation with fan |
