PAC240S56-CN
To see the prices, please log in or register here.
Article Nr 02131265
240W AC/DC power module
| Basic Information | |
| Part Number | 02131265 |
| Model | PAC240S56-CN |
| Description | 240 W PoE AC&HVDC Power Adapter |
| Technical Specifications | |
| Dimensions without packaging (H x W x D) [mm(in.)] | 150 mm x 65 mm x 133 mm (5.91 in. x 2.56 in. x 5.24 in.) |
| Weight without packaging [kg(lb)] | 1.47 kg (3.24 lb) |
| Number of inputs | 1 |
| Number of outputs | 4 |
| Rated output voltage [V] | 56 V DC |
| Rated input voltage [V] | 100 V AC to 240 V AC, 50/60 Hz 100 V DC to 250 V DC |
| Input voltage range [V] | 90 V AC to 290 V AC, 45 to 66 Hz 77 V DC to 300 V DC |
| Maximum input current [A] | 100 V AC to 240 V AC: 3 A 100 V DC to 138 V DC: 2.5 A 138 V DC to 250 V DC: 2 A |
| Rated output power [W] | Total power: 240 W |
| Power dissipation Mode | Natural heat dissipation without fans |
