Dimensions (H x W x D)

40 mm x 100 mm x 205 mm (1.6 in. x 3.9 in. x 8.1 in.)

Weight

0.8 kg (1.76 lb)

Rated input voltage range

-48 V DC to -60 V DC

Maximum input voltage range

-36 V DC to -72 V DC

Maximum input current

6 A

Maximum output current

12.5 A

Rated output voltage

12 V

Maximum output power

150 W

Part number

LS5M100PWD00: 02316784

ES0W2PSD0150: 02310JFD
