USG6525F-AC
To see the prices, please log in or register here.
USG6525F-AC
HiSecEngine USG6500F series AI firewalls are new-generation AI firewalls launched by Huawei for small enterprises, industry branches, and chain business organizations. With unique content detection engine (CDE), the USG6500F series can detect viruses with over 100 layers of compression and multi-layer hidden viruses. Through integrated deployment of the network and security controllers, network and security policies can be configured and delivered in a unified manner, reducing OPEX by 80%.
Basic Information | |
Part Number | 02355FCP |
Model | USG6525F |
Description | USG6525F(HTM)-AC Host(2*GE RJ45 + 8*GE COMBO + 2*10GE SFP+,1 AC power) |
Technical Specifications | |
Installation Type | Rack,Work bench |
Cabinet installation standard | Cabinet with a depth of 600 mm or above |
Chassis height[U] | 1 |
Wide[mm] | 442 mm |
Depth[mm] | 420 mm |
Height[mm] | 43.6 mm |
Weight without packaging[kg(lb)] | 5.46 (12.04) |
Weight with packaging[kg(lb)] | 7.83 (17.26) |
Typical power consumption[W] | 27.0 |
Maximum power consumption[W] | 36.8 |
Typical heat dissipation[BTU/hour] | 92.1 |
Maximum heat dissipation[BTU/hour] | 125.6 |
Heat dissipation mode | Absorbing cold air into the device |
Power supply mode | AC pluggable |
Rated input voltage[V] | 100 V to 240 V, 50 Hz/60 Hz |
Input voltage range[V] | 90 V to 290 V, 47 Hz to 63 Hz |
Maximum output power[W] | 60 W/power module |
Maximum input current[A] | 2 A/power module |
CPU | 1 CPU, 4 cores/CPU, up to 1.4 GHz |
Memory | 8 GB DDR4 ECC memory |
NOR Flash | 64 MB |
NAND Flash | 2 GB |
Hard disk | Optional, M.2 SSD, hot-swappable. For details, see the description of M.2 in Storage Devices > Hard Disk. |
Redundant power supply | Dual power modules can be purchased to form 1+1 redundancy backup. |
Number of power modules | 1 |
Number of fan modules | 1 |
Types of fans | Pluggable |
Noise at normal temperature (acoustic power)[dB(A)] | ≤55dB(A) |
Airflow direction | Front-to-back airflow |
Long-term operating temperature[°C(°F)] | 0°C to 45°C (32°F to 113°F) |
Storage temperature[°C(°F)] | –40°C to +70°C (–40°F to +158°F) |
Long-term operating relative humidity[RH] | 5% RH to 95% RH, non-condensing |
Storage relative humidity[RH] | 5% RH to 95% RH, non-condensing |
Long-term operating altitude[m(ft.)] | 0 m to 5000 m (0 ft to 16404 ft) |
Storage altitude[m(ft.)] | 0 m to 5000 m (0 ft to 16404 ft) |
MTBF[year] | 68.98 |
MTTR[hour] | 1 |
Availability | 0.999998 |
Console port | RJ45 |
Eth Management port | RJ45 |
